How Circuit Numbers Work in a Three-Phase Electrical Panel

Example of a Three Phase Panel Schedule

Affiliate Disclaimer

Some links contain affiliate links which means I may receive commission if you click a link and purchase a product.  These are all my own opinions - money will not sway me!

Both a Single Phase Panel and a Three Phase Panel are very similar. The only difference when looking at how circuit numbers work in a three-phase electrical panel is it has C phase, which is blue in color.

In other words, this is one extra circuit for the main conductors powering the three phase panel. A three phase panel has a total of 3 hot wires, and 1 neutral (if the panel requires a neutral, such as in a 4-wire wye system, as compared to a 3-wire delta-system [no neutral]).

Typically, a single phase panel has two hot wires (A Phase which is Red, and B Phase which is Black, and a Neutral which is White).

In a typically three-phase panel with a neutral (wye system), there are three hot wires. These are known as A, B, C.. or Red, Black, Blue, respectively.

If the panel is providing only motor loads, you can actually have a three phase panel without a neutral, which is known as a Delta configuration.

A pro-tip when trying to find C phase (blue wire) is that it is divisible by 6 (and minus 1.. so circuit 5 and circuit 6 would be blue, as well as circuit 11 and 12).


What We Cover in this Article:

  • How Do Circuit Numbers Work in a Three Phase Panel
    • Example Tables of Single-Phase + Three-Phase Circuit Numbers
    • How to Get 120V, 208V, and 240V…
  • How a Single Panel Differs from a 3 ϕ Panel
  • Why is Three Phase Better than Single Phase?

How to Count Circuits in a Three Phase Panel

To understand how circuit numbers work in a panel, you should start with how to read an electrical panel schedule (it has a video covering single and three phase panels). It will discusses how your bus bar works, and how to count circuits in general terms.

We will look a little further into understanding three phase circuits, and single-phase circuits, in this article:

Example of a Three Phase Panel Schedule
This is an example of a three phase panel schedule from my reading a panel schedule video. Notice it has A, B, C, written in Red, Black, and Blue. Notice that it keeps repeating (1 + 2 are A [Red], as well as circuits 7 + 8 [Red]. Circuits 3 + 4 are B [Black], and 5 + 6 are C [Blue]). It simply goes Red, Black, Blue over and over.. and Blue phase is divisible by 6 and minus one!!!

How a panel works is the left side is your odd numbered circuits, and the right side of the panel are your even numbered circuits. (This is important to know because of how circuit breakers are designed.. explained below).

Because of how a panel’s bus bar is designed, circuits 1 and 2 are the same phase (A). When you go down, 3 and 4 are the same phase (B), and if you keep going down, 5 and 6 are the same phase (C). This repeats OVER AND OVER, and you get your RED, BLACK, BLUE phases.

The numbers just increase to keep track of circuit numbers when reading electrical prints to help understand where electrical equipment is located throughout the building.

But all circuits from this electrical panel schedule are powered by the same 3 main conductors feeding the panel (the big wires powering the WHOLE panel).

Table Example of Three Phase Circuit Numbers

TABLE 1 below shows how each line is the same phase for an odd and even circuit (1 and 2 are A, 3 and 4 are B, 5 and 6 are C… and it repeats!).

Circuits – Left Side
(Odd Numbers)
3 Phase
(A, B, or C)
Circuits – Right Side
(Even Numbers)
1A (RED)2
3B (BLACK)4
5C (BLUE)6
7A8
9B10
11C12
13A14
15B16
17C18
TABLE 1
A (RED), B (BLACK), C (BLUE) repeats over and over. Notice the left side are odd numbers, and the right side are even numbers. Also notice that each line has two circuits.. so A Phase (Red) is Circuits #1 and #2.. B Phase (Black) is Circuits #3 and #4.. and C Phase (Blue) is Circuits #5 and #6!! When we get into multi-wire circuits, which means sharing a neutral between hot wires (ungrounded conductors), we cannot use Circuit #1 + #2 to share the neutral as it’s be A Phase + A Phase and overload the neutral! We can share a neutral with A + B, though, for example!

Here’s some very important things to know about counting circuits, and pulling wires as an electrician.

We Do NOT use both odd and even numbered circuits when grouping circuits to share a neutral. We only use odd numbers, or even numbers.

This is because circuit breakers are designed to only go on the left (odd numbers) or right (even numbers) of a panel. So a circuit breaker cannot work for both odd and even numbers.

Additionally, this circuit breaker MUST trip ALL circuits when “grouping circuits” or “sharing a neutral” with a breaker tie bar, so that if one circuit trips, ALL those circuits trip.

This is a VERY important safety feature for humans, as well as equipment (Let’s three circuits share a neutral, and somehow only 1 circuit trips, and the other two are still hot. Operation will still be okay, but if an electrician works on this dead circuit, thinking ALL circuits are not hot sharing the neutral, they can get severely shocked when opening up the neutral spice, which is like losing the neutral, and equipment could be powered by two hot wires, giving it WAY more voltage.. and BOOM!).

For example, 1, 3, 5 and a Neutral are all odd numbers, and are on the LEFT side of the panel. If we use a single neutral for circuits 1, 3, 5, it needs to be a three pole breaker so that if one circuit trips, all of the other circuits trip.

If a three phase motor is asking for 1, 3, 5 (and no neutral), the same thing applies.. we must use a three-pole breaker which trips all circuits as a safety precaution.

So that’s why we do not group odd and even numbers in a panel, because the circuit breaker is designed to be installed for only odd numbers or only even numbers going downward.

One thing to mention is if a panel starts to get full, you may see “tandem breakers” out there, which share the same phase.. You again have to be VERY careful with these, because you may THINK it’s two circuits, but it’s actually Circuit #1 A, and Circuit #1 B.. notice it’s STILL Circuit #1 which mean’s it’s A PHASE (Red), but it has #1 A and #1 B showing it has two separate switches using the SAME PHASE!

How to Get 120V, 208V, and 240V

Before moving on, it’s important to understand how to get different voltages.

When we use a single phase and a neutral, that will give us 120V. This is because we are using one hot wire (let’s say A Phase), and the neutral (which is actually the ground). We power most basic equipment this way like lights, TVs, or other house-old electrical items.

Now when we use TWO hot wires (two phases), this is where we can get into 208V or 240V. This difference simply comes down to the transformer that is feeding the main service panel.

If it’s a typical home, the main panel is fed with 240V. If it’s a commercial building, it’s typically powered with a three-phase system, meaning we get 208V when using two hot wires OR three hot wires! This is because in three-phase if we go A + B it’s single phase 208V.. and if we use all three wires, get three-phase 208V..

It sounds confusing, but that’s why it’s SO important to understand your equipment schedule, because sometimes you can have single-phase 208V to certain equipment (just two hot wires), and sometimes you need to have three-phase 208V (all three hot wires!)


How a Single Panel Differs from a 3 ϕ Panel

A single phase panel actually has TWO HOT WIRES, and a three phase panel has THREE HOT WIRES (with C Phase / Blue being the difference), that’s it!

It goes A (RED), B (BLACK), and repeats! Let me give you a chart:

Circuits – Left Side
(Odd Numbers)
Single Phase (A, B)
Yes, two hots wires!
Circuits – Right Side
(Even Numbers)
1A (RED)2
3B (BLACK)4
5A (RED)6
7B (BLACK)8
9A10
11B12
TABLE 2
As you can see, the EXACT same theory applies that 1 + 2 are A Phase (RED), and 3 + 4 are B Phase (BLACK). It repeats over and over, except it does not have C Phase (BLUE), which would be 5 + 6. Instead, in a single phase panel, A Phase continues at 5 + 6, and B Phase follows after with circuits 7 + 8. If we want 240V, we just use both A + B Phase in a home (such as on an oven)… If it’s a three-phase panel, you can get single phase 208V with two hot wires, or three-phase 208V with all three hot wires!

So back to a three phase panel. Single phase is the same thing when sharing the neutral, except for one less hot wire (C Phase).. that is all.. it’s not more complicated than that.. except when in school.. we use root 3 (√3) in our calculations to find ampacity.. too technical for this article though.


Is Three Phase Better than Single Phase?

The answer is yes, three-phase is better.. and there’s many reasons for it actually!

First is because a three-phase system has three phases. Think of “phase” as timing. When you get into multi-wire branch circuits, which means sharing a neutral between hot wires, you can use one neutral for three wires! This is because each phase is 120° out of phase.. which means they each “fire” at slightly different timings, allowing the neutral to not get as hot.

In short, it allows you to use less wires. Copper is expensive, and if a commercial building has 100+ circuits, electrical companies can be saving $1000’s of dollars a year by sharing neutrals.

Second is motors are much more efficient because the 120° timings allows each phase to keep powering the motor without long periods of gaps. Remember, in North America, electricity operates at 60Hz.. so we can’t change how fast electricity “triggers”.. so by using the third C Phase, it’s essentially like “triggering” electrical equipment faster, which can allow motor sizes to be smaller (again, reducing cost!)

Third is wire size.. Because of the 120° timings, as well as sharing a neutral, we are able to combine all benefits of three-phase, and reduce wire size, amount of wires used, reduce labor times.. and many others you can think of.

Are there Downsides to Three Phase Systems?

No, not really! The things to be careful of in a three-phase system, also apply to a single-phase electrical system. This is mainly when sharing a neutral that the circuit breaker MUST TRIP ALL CIRCUITS if any circuit trips while sharing a neutral, or if a piece of electrical equipment uses all conductors to be powered.

When you lose a neutral, other equipment can get much more voltage because of the science of electricity. For example, your TV that requires 120V could get 180V sent to it, and can severely damage the electrical components!

This is a major downfall of multi-wire branch circuits, and applies to both single-phase and three-phase systems.

Wrapping Up Counting Circuits in Three Phase Panels

So I hope that helps you understand how to count circuits in an electrical panel.

Electrical panels have ODD and EVEN circuit numbers. Odd numbers are on the left, even numbers are on the right.

A “clean set of wires” would be 1, 3, 5, and N. You can do stuff like 3, 5, 7, and N, but it gets really tricky to troubleshoot if there is no organization.. and are called “dirty sets” on an electrical jobsite.

To keep the “clean sets” going, here’s an example..

1, 3, N let’s say power different banks of lights. Circuit 1 (A Phase) and Circuit 3 (B Phase) share a neutral and go back to the panel. All is good!

But now Circuit 5, which could have been a part of that “clean set”, needs to be pulled way to the other side of the building. In this case, we’d just run Circuit 5 with ITS OWN Neutral.

Then if we go back to Circuit 7 (A Phase), it starts over, and we decide if we can use Circuit 7, 9, 11, N in a clean set to save wire and labor time.

There are downfalls of sharing a neutral besides losing a neutral, like harmonics and similar studies when powering computers and electronics.. so ideally, every circuit SHOULD have its own neutral, but sometimes the job’s bid cost doesn’t allow for that.

Also, sometimes your jobsite specs specify no neutral sharing.. so keep an eye out!

Make sure to leave a comment below if you have questions.. or laugh at some funny electrical jokes!
